Bussmann 5ACLS-3R - Medium Voltage Current-Limiting Fuse 100A (5080V, 50kA AIC)

Bussmann 5ACLS-3R is a medium voltage current-limiting fuse designed for protecting electrical distribution systems and equipment. It features a 5080V voltage rating and 100A current rating, providing reliable circuit protection with a 50kA interrupting rating at 5.08V. The fuse construction includes a single-barrel design with ferrule connections, measuring 3 inches in diameter and 15.9 inches in length with a weight of 5.8 lb. It complies with ANSI C37.46 standards and carries UL recognition under Guide MSSS2 File E60757, ensuring industry-standard performance and safety. This R-class fuse is typically applied in industrial power distribution systems, motor circuits, and transformer protection applications where medium voltage protection is required.

Key Features & Specifications

• Type: Medium Voltage Current-Limiting Fuse, ACLS type, single barrel construction with ferrule connections
• Voltage Rating: 5080V AC
• Current Rating: 100A
• Dimensions: 3" diameter x 15.9" length
• Standards: ANSI C37.46, UL Recognized Guide MSSS2 File E60757
• Applications: Industrial power distribution systems, motor protection, transformer circuits
• AIC rating: [email protected]
• Class Rating: R
• Connection: Ferrule
• Barrels: 1
• Weight: 5.8 lb
• Family: CLS
• Country of Origin: Dominican Republic

Product Identification

• UPC: 051712527859
• GTIN: 00786670221340
