Bussmannn 5ACLS-24R - Medium Voltage Current-Limiting Fuse 5080V/450A (50kA AIC, Class R)

Bussmannn 5ACLS-24R is a medium-voltage current-limiting fuse designed for high-voltage circuit protection in industrial power systems. Rated for 5080V AC operation with a 450A current rating, this Class R fuse features a ferrule connection type and dual-barrel construction housed in a 15.9-inch long, 3-inch diameter cylindrical body weighing 18.4 lb. Certified to IEEE Std. C37.41, it delivers 50kA interrupting capacity at 5.08V for reliable protection in utility substations, industrial switchgear, and heavy equipment power distribution networks.

Key Features & Specifications

• Type: ACLS current-limiting fuse with dual ferrule connection
• Voltage Rating: 5080V AC
• Current Rating: 450A
• Dimensions: 15.9" L x 3" W x 3" H (403.9mm x 76.2mm x 76.2mm)
• Weight: 18.4 lb (8.35 kg)
• Diameter: 3" (76.2mm)
• Class Rating: R
• Connection: Ferrule
• Barrels: 2
• Certification: IEEE Std. C37.41
• AIC Rating: [email protected]
• Applications: Industrial switchgear, utility substations, heavy equipment power distribution

Product Identification

• UPC: 051712527828
• GTIN: 00786670221722
