Bussmann 55GDMSJ65E - Class E Fuse 65A 5500V (65kA AIC)

Bussmann
Price
Save $-3,314.88
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Bussmann 55GDMSJ65E is a medium voltage fuse designed for high-interrupting capacity protection in industrial power distribution systems. It features a 65A current rating and a 5500V voltage rating, providing reliable overcurrent protection for medium voltage circuits. The fuse is constructed with a single-barrel, ferrule connection design, measures 20.078 inches in length with a 51mm diameter, and has a clip center spacing of 442mm for secure mounting. It complies with Class E fuse standards and is engineered to safely interrupt faults with an AIC rating of 65kA at 5.5kV. Typical applications include protecting transformers, motors, and feeders in utility and industrial settings.

Key Features & Specifications
  • Type: GDMSJ Class E medium voltage fuse with ferrule connection and single-barrel construction
  • Voltage Rating: 5500V
  • Current Rating: 65A
  • Dimensions: 20.078 in x 2.106 in x 2.007 in (Length/Depth x Height x Width)
  • Standards: Class E fuse rating
  • Applications: Protection for transformers, motors, and feeders in industrial power distribution
  • AIC rating: [email protected]
  • Connection: Ferrule
  • Barrels: 1
  • Clip Center: 442mm
  • Diameter: 51mm
  • Weight: 14.79 lb


Product Identification
  • UPC: 05171269202
  • GTIN: 00051712692021
