Siemens 3VA94770CB10 - Operating Mechanism for 400-600A 3VA6 Breakers
Siemens 3VA94770CB10 - Operating Mechanism for 400-600A 3VA6 Breakers

Siemens 3VA94770CB10 - Operating Mechanism for 400-600A 3VA6 Breakers

Siemens
Price
Save $-440.60
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Siemens 3VA94770CB10 is a steel operating mechanism designed for Max-Flex operators used with 400-600A 3VA6 frame circuit breakers, providing reliable manual control for Sentron series molded case circuit breakers. This mechanism operates within a temperature range of -13°F to 158°F (-25°C to 70°C) and is certified UL Listed for safety compliance. The unit measures 10.984 x 5.984 x 2.008 inches and weighs 2.264 lb, featuring durable steel construction for industrial environments. It is compatible with 3VA5 and 3VA6 series circuit breakers and supports Max-Flex manual and motor operators for secure circuit breaker control. Typical applications include industrial power distribution systems requiring robust, UL-certified operating mechanisms for molded case circuit breakers.

Key Features & Specifications
  • Manufacturer: Siemens
  • Type: Operating Mechanism
  • Family: Sentron Series
  • Item Subcategory: Molded Case
  • Compatible Series: 3VA5 and 3VA6
  • Frame Size: 400-600A
  • Material: Steel
  • Operator Type: Max-Flex Manual and Motor Operator
  • Dimensions: 10.984 x 5.984 x 2.008 inch
  • Weight: 2.264 lb
  • Standards: UL Listed
  • Certification: UL Listed, CE Certified, RoHS Compliant, WEEE 2012/19/EU
  • Temp Rating: -13°F-158°F (-25°C-70°C)
  • Country of Origin: Mexico
  • ECCN: EAR99


Product Identification
  • UPC: 804766758218
  • GTIN: 4042949011774
