Siemens 3VA61106HL310AA0 - Molded Case 100A 600V Feed-Thru
Siemens 3VA61106HL310AA0 - Molded Case 100A 600V Feed-Thru

Siemens 3VA61106HL310AA0 - Molded Case 100A 600V Feed-Thru

Siemens
Price
Save $1,345.12
/
Condition
  • Low stock - 4 items left
  • Backordered, shipping soon
Call for Price
Siemens 3VA61106HL310AA0 Circuit Breaker - Molded Case 3VA6 100A 600V Feed-Thru (UL Listed) The Siemens 3VA61106HL310AA0 is a molded case circuit breaker from the Sentron Series designed for primary overcurrent and short-circuit protection in industrial power distribution systems. This 3VA6 model is rated for 600V AC and 100A continuous current, with a feed-thru connection configuration and a compact frame size that supports efficient panel integration. Constructed with a robust thermoplastic housing and weighing 4.564 lb, it features a thermal-magnetic trip mechanism for reliable protection against overloads and faults. The breaker is UL Listed and certified, operating within a temperature range of -13°F to 158°F (-25°C to 70°C), and is suitable for use in switchboards, panelboards, and motor control centers.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Sentron Series, 3VA6
  • Voltage Rating: 600V AC
  • Current Rating: 100A
  • Connection: Feed-Thru
  • Standards: UL Listed
  • Certification: UL Listed
  • Temp Rating: -13°F to 158°F (-25°C to 70°C)
  • Weight: 4.564 lb
  • Trip Type: Thermal-Magnetic
  • Frame Size: 3VA6
  • Breaker Type: 3VA
  • Circuit Breaker Mounting Style: Fixed
  • Terminal Connection: Feed-Thru
  • Frequency Rating: 50/60 Hz
  • Phase Connection: 3-Phase
  • Installation Type: Panel-Mount
  • Item QTY: 1
  • Breaker Frame: 3VA6
  • Operating Temperature Maximum Celsius: 70°C


Product Identification
  • UPC: 80476630679
  • GTIN: 00804766306792
