Siemens 3VA5150-5ED11-0AA0 - Molded Case Breaker 50A 1-Pole
Siemens 3VA5150-5ED11-0AA0 - Molded Case Breaker 50A 1-Pole

Siemens 3VA5150-5ED11-0AA0 - Molded Case Breaker 50A 1-Pole

Siemens
Price
Save $245.77
/
Condition
  • Low stock - 2 items left
  • Backordered, shipping soon
Call for Price
Siemens 3VA5150-5ED11-0AA0 is a 1-pole molded case circuit breaker from the Sentron Series, designed for thermal-magnetic protection (LI functions) in industrial applications. It is rated for 50A continuous current at 415V AC, with a high interrupting capacity of 35kA at 277V AC. The unit measures 5.512 x 1.339 x 4.252 inches, weighs 0.844 lb, and features a feed-thru connection with a TM210 trip type. It is UL Listed and certified for operation within a temperature range of -13°F to 158°F (-25°C to 70°C). This breaker is suitable for single-phase branch circuit protection in panelboards and industrial control equipment.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal Magnetic, LI Protection
  • Voltage Rating: 415V AC
  • Current Rating: 50A
  • Dimensions: 5.512 x 1.339 x 4.252 inch
  • Standards: UL Listed
  • Applications: Branch circuit protection, industrial control panels
  • Switch Type: Circuit Breaker
  • Configuration: 1 Pole
  • Temp Rating: -13°F-158°F (-25°C-70°C)
  • Shipping Dimensions: 5.512 x 1.339 x 4.252 inch
  • Phase: 1
  • Voltage: 415V AC
  • Amperage: 50A
  • AIC rating: 35kA@277V
  • Connection: Feed-Thru
  • Poles: 1
  • Protection: Thermal Magnetic
  • Functions: LI
  • Trip Type: TM210
  • Breaker Type: Molded Case
  • Certification: UL Listed
  • Circuit Breaker Mounting Style: Fixed
  • Terminal Connection: Feed-Thru
  • Frequency Rating: 50/60 Hz
  • Phase Connection: Single Phase
  • Standards: UL 489
  • Installation Type: Fixed
  • Item QTY: 1
  • Breaker Frame: 3VA
  • Current Rating: 50A
  • Operating Temperature Maximum Celsius: 70°C
  • Weight: 0.844 lb


Product Identification
  • UPC: 804766300011
  • GTIN: 00804766300011
