Siemens 3VA4145-4ED34-0AA0 - Molded Case 45A 600V AC
Siemens 3VA4145-4ED34-0AA0 - Molded Case 45A 600V AC

Siemens 3VA4145-4ED34-0AA0 - Molded Case 45A 600V AC

Siemens
Price
Save $444.26
/
Condition
  • Low stock - 2 items left
  • Backordered, shipping soon
Call for Price
The Siemens 3VA4145-4ED34-0AA0 is a 3-pole molded case circuit breaker from the Sentron Series, designed for thermal-magnetic protection with LI (long-time and instantaneous) functions. It is rated for 45A continuous current at 600V AC, with an interrupting capacity of 25kA at 480V, and features a TM210 trip type. The unit measures 6.299 x 5.315 x 3.465 inches, weighs 1.638 lb, and uses a bolt-on connection with load-side lugs. It is UL Listed and certified, operating within a temperature range of -13°F to 158°F (-25°C to 70°C). This breaker is suited for industrial applications requiring reliable overcurrent protection in 3-phase systems.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal Magnetic, Sentron Series
  • Voltage Rating: 600V AC
  • Current Rating: 45A
  • Dimensions: 6.299 x 5.315 x 3.465 inch
  • Standards: UL Listed
  • Applications: Industrial overcurrent protection for 3-phase systems
  • Switch Type: Circuit Breaker
  • Configuration: 3-Pole
  • Coil Voltage Maximum: Not specified
  • Temp Rating: -13°F-158°F (-25°C-70°C)
  • Shipping Dimensions: Not specified
  • Phase: 3
  • Voltage: 600V AC
  • Amperage: 45A
  • AIC rating: 25kA@480V
  • Connection: Bolt-On
  • Poles: 3
  • Protection: Thermal Magnetic
  • Functions: LI
  • Frame Size: 125
  • Trip Type: TM210
  • Panel Type: Not specified
  • Breaker Type: Molded Case
  • Control Voltage Minimum: Not specified
  • Control Voltage Maximum: Not specified
  • MCM Size: Not specified
  • Metal Type: Not specified
  • Panel Style: Not specified
  • Bus Type: Not specified
  • Fuse Class: Not specified
  • Insulation Temperature: Not specified
  • Inductance: Not specified
  • Impedance: Not specified
  • Barrels: Not specified
  • Class Rating: Not specified
  • Diameter: Not specified
  • Velocity: Not specified
  • Clip Center: Not specified
  • Clas: Not specified
  • Mounting: Not specified
  • Hz: Not specified
  • Coil Material: Not specified
  • Horse Power: Not specified
  • Aux Contacts: Not specified
  • CPT: Not specified
  • Full Load Amps: Not specified
  • Dist Voltage: Not specified
  • Bucket Size: Not specified
  • Bucket Style: Not specified
  • Bucket Type: Not specified
  • Full Load Amp Maximum: Not specified
  • Full Load Amp Minimum: Not specified
  • Enclosure: Not specified
  • Relay Style: Not specified
  • Coil Voltage Minimum: Not specified
  • Wire: Not specified
  • Amperage Maximum: Not specified
  • Amperage Minimum: Not specified
  • Nema Rating: Not specified
  • Switch Style: Not specified
  • Wire Size: Not specified
  • Certification: UL Listed
  • Circuit Breaker Mounting Style: Not specified
  • Terminal Connection: Load Side Lug
  • Frequency Rating: Not specified
  • Phase Connection: Not specified
  • Standards: UL Listed
  • Compatible Frames: Not specified
  • Installation Type: Not specified
  • Item QTY: Not specified
  • Nema Starter Size: Not specified
  • Breaker Frame: Not specified
  • Current Rating: 45A
  • Reverse Standoff Voltage: Not specified
  • Watts: Not specified
  • Peak Pulse Current: Not specified
  • Breakdown Voltage (MIN VBR@IT ) (V): Not specified
  • Breakdown Voltage (VBR@IT) (V): Not specified
  • Polarity: Not specified
  • Operating Temperature Maximum Celsius: Not specified
  • Max Clamp Voltage: Not specified
  • On-State Current: Not specified


Product Identification
  • UPC: 804766943867
  • GTIN: 804766943867
