Siemens 3VA4135-5ED34-0AA0 - Molded Case 35A 600V AC
Siemens 3VA4135-5ED34-0AA0 - Molded Case 35A 600V AC

Siemens 3VA4135-5ED34-0AA0 - Molded Case 35A 600V AC

Siemens
Price
Save $-297.65
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Siemens 3VA4135-5ED34-0AA0 is a 3-pole molded case circuit breaker from the Sentron Series, designed for thermal-magnetic protection (LI functions) in industrial power distribution systems. Rated at 35A and 600V AC, it delivers a 35kA interrupting capacity at 480V and operates in three-phase, bolt-on configurations with a TM210 trip type. The unit measures 6.299 x 5.315 x 3.465 inches, weighs 1.638 lb, and features load side lug terminals within a 125A frame size, operating within a temperature range of -13°F to 158°F (-25°C to 70°C). It is UL Listed and certified, ensuring compliance with North American safety standards. This breaker is typically applied in commercial and industrial panelboards, switchboards, and motor control centers requiring reliable overcurrent protection.

Key Features & Specifications
  • Type: Molded Case, Thermal Magnetic, 3VA
  • Voltage Rating: 600V AC
  • Current Rating: 35A
  • Poles: 3
  • Frame Size: 125
  • Trip Type: TM210
  • AIC Rating: 35kA@480V
  • Connection: Bolt-On
  • Terminal Connection: Load Side Lug
  • Functions: LI
  • Phase: 3
  • Temp Rating: -13°F-158°F (-25°C-70°C)
  • Dimensions: 6.299 x 5.315 x 3.465 inch
  • Weight: 1.638 lb
  • Standards: UL Listed
  • Certification: UL Listed
  • Family: Sentron Series
  • Country of Origin: Mexico


Product Identification
  • UPC: 804766943768
  • GTIN: 00804766943768
