Siemens 3RV20214FA15 - Motor Protection Circuit Breaker 40A 690V
Siemens 3RV20214FA15 - Motor Protection Circuit Breaker 40A 690V

Siemens 3RV20214FA15 - Motor Protection Circuit Breaker 40A 690V

Siemens
Price
Save $408.73
/
Condition
  • Low stock - 9 items left
  • Backordered, shipping soon
Call for Price
Siemens 3RV20214FA15 is a molded case motor protection circuit breaker from the Sirius family, designed to safeguard motor circuits against overloads and short circuits. It is rated for 690 VAC operation with a 40 A thermomagnetic trip unit adjustable from 34 to 40 A, providing a 3 kA interrupting capacity for 50/60 Hz systems. The breaker features a compact S0 frame measuring 4.016 x 1.929 x 4.016 inches and weighing 0.877 lb, with screw terminals for secure wiring and DIN rail mounting. It is built with 3 poles and includes auxiliary contacts rated 1NO-1NC, enclosed in an IP20-rated housing. This device is manufactured in Germany and is suitable for industrial motor control applications requiring reliable circuit protection.

Key Features & Specifications
  • Type: 3RV
  • Family: Sirius
  • Item Subcategory: Molded Case
  • Country of Origin: Germany
  • Dimensions: 4.016 x 1.929 x 4.016 inch
  • Weight: 0.877 lb
  • Voltage Rating: 690 VAC
  • Amperage: 40 A (trip range 34-40 A)
  • Number of Poles: 3
  • Mounting Type: DIN Rail
  • Interrupt Rating: 3 kA
  • Frame/Series: S0
  • Trip Unit: Thermomagnetic
  • Auxiliary Contacts: 1NO-1NC
  • Enclosure Type: IP20
  • Frequency: 50/60 Hz
  • Connection Type: Screw Terminals
  • Power Rating: 39 kW


Product Identification
  • UPC: 662643924541
