Siemens 3RT19655AB31 - Surge Suppressor 600V AC 20A
Siemens 3RT19655AB31 - Surge Suppressor 600V AC 20A

Siemens 3RT19655AB31 - Surge Suppressor 600V AC 20A

Siemens
Price
Save $-106.53
/
Condition
  • Low stock - 3 items left
  • Backordered, shipping soon
Call for Price
The Siemens 3RT19655AB31 is a high-performance surge suppressor module designed to protect industrial control systems from transient overvoltages. This device is rated for a maximum voltage of 600V AC and a continuous current of 20A, ensuring robust protection for sensitive equipment. Constructed with a compact, modular design, it weighs 1.83 lb and features integrated varistor technology for reliable surge clamping. The module complies with IEC and UL standards for surge protective devices, making it suitable for use in motor control centers, switchgear, and automation panels. Typical applications include protecting contactors, relays, and programmable logic controllers in manufacturing and process industries.

Key Features & Specifications
  • Type: Surge suppressor module, varistor-based, modular design
  • Voltage Rating: 600V AC
  • Current Rating: 20A
  • Weight: 1.83 lb
  • Standards: IEC, UL
  • Applications: Industrial control systems, motor control centers, switchgear, automation panels
  • Protection: Surge/transient overvoltage
  • Mounting: Modular, DIN rail or panel
  • Frequency Rating: 50/60 Hz
  • Operating Temperature Maximum Celsius: 60°C
  • Max Clamp Voltage: 1200V
  • Peak Pulse Current: 10kA
  • Polarity: Bidirectional


Product Identification
  • UPC: 75455477419
  • GTIN: 00754554774190
