Eaton 38RBA2-DL - RBA2 Current-Limiting Fuse 600VAC/200A (200kA Interrupting Rating)

Eaton 38RBA2-DL is a current-limiting fuse designed for robust circuit protection in industrial power distribution systems. Rated for 600V AC with a 200A current capacity, it features a durable ceramic body construction with silver-sand filler for reliable arc quenching. The fuse meets UL 248-12 standards and carries a 200kA interrupting rating for high-fault applications. Its compact cylindrical design (38mm diameter) integrates into panelboards and switchgear, providing overcurrent protection for motors, transformers, and feeder circuits in commercial and industrial facilities.

Key Features & Specifications

• Type: RBA2 current-limiting fuse with ceramic body and silver-sand filler
• Voltage Rating: 600V AC
• Current Rating: 200A
• Dimensions: 38mm diameter cylindrical form factor
• Standards: UL 248-12 compliant
• Applications: Motor protection, transformer feeders, industrial switchgear
• Interrupting Rating: 200kA
• Construction: Ceramic housing with live parts section
• Weight: 10.6 lb
• Country of Origin: United States

Product Identification

• UPC: 78667025152
• GTIN: 00786670251521
