S&C Electric 3500R2 - SMD-50 Current-Limiting Fuse 15.5kV/200A (50kA Interrupting Rating)
S&C Electric 3500R2 - SMD-50 Current-Limiting Fuse 15.5kV/200A (50kA Interrupting Rating)
S&C Electric 3500R2 - SMD-50 Current-Limiting Fuse 15.5kV/200A (50kA Interrupting Rating)
S&C Electric 3500R2 - SMD-50 Current-Limiting Fuse 15.5kV/200A (50kA Interrupting Rating)

S&C Electric 3500R2 - SMD-50 Current-Limiting Fuse 15.5kV/200A (50kA Interrupting Rating)

S&C Electric
Price
Save $0
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
S&C Electric 3500R2 is a current-limiting fuse designed for high-voltage circuit protection in industrial power distribution systems. Rated for 15.5kV AC operation with a 200A continuous current rating, it features a robust silver-sand fuse element housed in a durable fiberglass-reinforced epoxy tube for arc-quenching performance. The fuse meets IEEE C37.40 standards for distribution-class fuses and is UL-recognized for use in switchgear, transformers, and capacitor banks. Its 24 lb live-part construction ensures reliable fault interruption in utility substations and heavy industrial facilities.

Key Features & Specifications
  • Type: SMD-50 current-limiting fuse with silver-sand element and fiberglass tube
  • Voltage Rating: 15.5kV AC
  • Current Rating: 200A continuous
  • Dimensions: 3500R2 series standard footprint
  • Standards: IEEE C37.40, UL recognized
  • Applications: Switchgear, transformers, capacitor protection
  • Section: Live Parts
  • Weight: 24 lb
  • Fuse Class: Distribution class
  • Interrupting Rating: 50kA symmetrical
