Bussmann 2NCLPT-2E - Medium Voltage Fuse 2A 2475V (Class E, 40kA AIC)

Bussmann 2NCLPT-2E is a medium voltage fuse designed for overcurrent protection in industrial power distribution systems. It features a 2A current rating and a 2475V voltage rating, providing reliable circuit interruption. The fuse is constructed with a compact ferrule connection design, measuring 4.5 inches in length with a 0.81-inch diameter and weighing 0.9 lb. It complies with IEEE Std. C37.41 certification standards and offers a 40kA interrupting rating at 2475V. Typical applications include protection for transformers, motors, and capacitor banks in medium voltage electrical systems.

Key Features & Specifications

• Type: NCLPT medium voltage fuse with single barrel ferrule connection
• Voltage Rating: 2475V AC
• Current Rating: 2A
• Dimensions: 4.5" L × 0.81" W × 0.81" H
• Standards: IEEE Std. C37.41
• Applications: Transformer, motor, and capacitor bank protection
• Class Rating: E
• AIC rating: [email protected]
• Connection: Ferrule
• Barrels: 1
• Diameter: 0.81 inches
• Weight: 0.9 lb
• Country of Origin: United States

Product Identification

• UPC: 051712527637
• GTIN: 00786670214335
