Eaton 2CLS-3R - CLS Medium Voltage Fuse 100A (2540V, 50kA AIC)

Eaton
Price
Save $986.30
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Eaton 2CLS-3R is a medium-voltage current-limiting fuse designed for protecting transformers, motors, and feeders in industrial power systems. It is rated for 2540V AC systems with a 100A continuous current rating and an interrupting capacity of 50kA at 2.54kV. The fuse features a single-barrel, ferrule-connection construction with a diameter of 3 inches and a clip center spacing of 7 inches, housed within a robust 10.8-inch long body. It complies with the IEEE Std. C37.41 standard for design tests and is classified as a Class R fuse for rejection of lower-interrupting capacity fuses. Typical applications include service entrance equipment, capacitor banks, and medium-voltage switchgear where high fault current protection is required.

Key Features & Specifications
  • Type: CLS, single-barrel, current-limiting medium-voltage fuse with ferrule connection
  • Voltage Rating: 2540V AC
  • Current Rating: 100A
  • Dimensions: 10.8 in L x 3 in H x 3 in W
  • Standards: IEEE Std. C37.41
  • Applications: Transformer, motor, and feeder protection in industrial power systems
  • AIC rating: 50kA @ 2.54kV
  • Class Rating: R
  • Connection: Ferrule
  • Barrels: 1
  • Diameter: 3 in
  • Clip Center: 7 in
  • Weight: 6 lb


Product Identification
  • UPC: 786670500896
  • GTIN: 00786670500896
