Eaton 2ACLS-2R - Medium Voltage Fuse 70A 2540V (Class R)

Eaton
Price
Save $926.13
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Eaton 2ACLS-2R is a medium voltage current-limiting fuse designed for the protection of transformers, motors, and feeders in industrial power systems. It features a 70A current rating and a 2540V voltage rating, with a high interrupting capacity of 50kA at 2.54kV. The fuse is constructed as a single-barrel, Class R device with a diameter of 3 inches and overall dimensions of 10.8 in x 4.2 in x 3 in, weighing 5.9 lb. It is engineered to comply with IEEE Std. C37.41 and is typically applied in medium-voltage switchgear and motor starters for reliable short-circuit protection.

Key Features & Specifications
  • Type: Medium Voltage Current-Limiting (ACLS), Single Barrel
  • Voltage Rating: 2540V
  • Current Rating: 70A
  • Dimensions: 10.8 in L x 4.2 in H x 3 in W
  • Standards: IEEE Std. C37.41
  • Applications: Transformer, Motor, and Feeder Protection
  • Class Rating: R
  • AIC rating: 50kA @ 2.54kV
  • Diameter: 3 in
  • Weight: 5.9 lb
  • Barrels: 1
  • Family: CLS
  • Country of Origin: Canada


Product Identification
  • UPC: 786670220695
  • GTIN: 00786670220695
