Brush 24SFMAJ65 - Medium Voltage Fuse 65A (24 kV Class E)
Brush 24SFMAJ65 - Medium Voltage Fuse 65A (24 kV Class E)

Brush 24SFMAJ65 - Medium Voltage Fuse 65A (24 kV Class E)

Brush
Price
Save $0
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Brush 24SFMAJ65 is a medium voltage current-limiting fuse designed for industrial circuit protection applications. This Class E fuse features a 24 kV voltage rating and 65A current rating for reliable overcurrent protection in demanding environments. The fuse construction includes a 3.35-inch diameter single-barrel design with DIN connection system and 17.4-inch clip center spacing. It complies with industry standards for medium voltage protection systems and is typically deployed in industrial power distribution, motor control centers, and electrical substations.

Key Features & Specifications
  • Type: Medium voltage current-limiting fuse, Class E rating, single-barrel construction
  • Voltage Rating: 24000V AC
  • Current Rating: 65A
  • Dimensions: 3.35-inch diameter, 17.4-inch clip center spacing
  • Standards: Class E fuse standards compliance
  • Applications: Industrial power distribution, motor protection, electrical substations
  • Connection: DIN
  • Barrels: 1
  • Weight: 13 lb
  • Class Rating: E
