Cutler Hammer 225-007-951 is a medium voltage Amp-Trap fuse designed for high-interrupting capacity circuit protection in industrial power systems. It features a 5500V voltage rating and a 300A current rating for robust electrical performance. The fuse is constructed with a single-barrel design, measures 3 inches in diameter with a 21.25-inch clip center, and utilizes a clip-lock connection system for secure installation. This Class E rated fuse complies with industry standards for medium voltage applications and provides 50kA interrupting capacity at 15.5kV for reliable fault protection. Typical applications include motor control centers, transformers, and feeder circuits in industrial facilities requiring high-performance protection.

Key Features & Specifications
  • Type: Medium Voltage Amp-Trap Fuse, Class E, Single Barrel
  • Voltage Rating: 5500V
  • Current Rating: 300A
  • Dimensions: 3" Diameter
  • Standards: Class E Rating
  • Applications: Industrial Power Systems, Motor Control Centers, Transformers
  • AIC Rating: [email protected]
  • Connection: Clip-Lock
  • Barrels: 1
  • Clip Center: 21.25 inches
  • Weight: 16 lb
  • Family: Amp-Trap
