Bussmann 170M5748 Low Voltage 1250V 800A Fuse - Essential Electric Supply
Bussmann 170M5748 Low Voltage 1250V 800A Fuse - Essential Electric Supply

Bussmann 170M5748 - FKE115 Fuse 800A 1250V (100kA AIC)

Bussmann
Price
Save $2,007.59
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
The Bussmann 170M5748 is a low-voltage, high-interrupting capacity fuse designed to provide reliable protection for industrial power distribution systems. It features a 1250V AC voltage rating and a 800A current rating, housed within a robust 280 mm x 65 mm x 180 mm (Length x Height x Width) body with a bolt-on connection for secure installation. This fuse meets the aR (partial-range) class rating and is engineered to safely interrupt fault currents up to 100kA at its rated voltage, ensuring compliance with stringent protection requirements. Its construction is suited for demanding applications such as protecting feeders, busways, and transformers in industrial and commercial electrical infrastructure.

Key Features & Specifications
  • Type: Low Voltage Fuse, FKE115, aR (partial-range) class, bolt-on connection
  • Voltage Rating: 1250V AC
  • Current Rating: 800A
  • Dimensions: 280 mm x 65 mm x 180 mm (L x H x W)
  • Weight: 3.795 lb
  • AIC Rating: 100kA @ 1250V
  • Class Rating: aR
  • Connection: Bolt On


Product Identification
  • UPC: 051712262385
  • GTIN: 00051712262385
