Littelfuse 15NLE2125E - E-Rated Medium Voltage Fuse [email protected] (60kA AIC)

Littelfuse 15NLE2125E is a medium voltage E-Rated fuse designed for high-voltage circuit protection in industrial power systems. This 15.5kV-rated fuse features a 125A current rating and 60kA interrupting capacity at rated voltage, housed in a durable dual-barrel design with 20-inch clip centers for secure mounting. Its 3-inch diameter construction meets stringent E-class standards for reliable overcurrent protection in demanding environments. The fuse complies with industry standards for medium-voltage applications, making it suitable for transformer protection, motor circuits, and feeder protection in utility and industrial power distribution systems.

Key Features & Specifications

• Type: E-Rated medium voltage current-limiting fuse with dual-barrel construction
• Voltage Rating: 15,500V AC
• Current Rating: 125A
• Dimensions: 3" diameter, 20" clip center spacing
• Standards: Meets E-class fuse requirements
• Applications: Transformer protection, industrial motor circuits, power distribution
• AIC rating: [email protected]
• Barrels: 2
• Class Rating: E
• Weight: 27 lb

Product Identification

• UPC: 07945804225
• GTIN: 00079458042252
