Bussmann 15NCLPT-1E-A - Class E Medium Voltage Fuse 1A 15.5kV

Bussmann
Price
Save $-143.29
/
Title
  • Low stock - 2 items left
  • Backordered, shipping soon
Call for Price
Bussmann 15NCLPT-1E-A is a medium voltage current-limiting power fuse designed for protecting transformers, motors, and feeders in industrial power systems. It features a 1A current rating and a 15.5kV voltage rating, with a single-barrel ferrule connection and a compact form factor measuring 12.9 inches in length with a 1.62-inch diameter. The fuse is constructed to meet IEEE Std. C37.41 and provides a 50kA interrupting rating at 15.5kV, ensuring reliable protection for medium-voltage circuits. Its Class E rating and specific 11.5-inch clip center dimension make it suitable for integration into designated switchgear and fuse holders.

Key Features & Specifications
  • Type: NCLPT, Medium Voltage Current-Limiting Power Fuse, Single Barrel
  • Voltage Rating: 15500V AC
  • Current Rating: 1A
  • Dimensions: 12.9 in L x 1.6 in H x 1.6 in W (1.62 in Diameter)
  • Weight: 0.001 lb
  • Standards: IEEE Std. C37.41
  • Applications: Transformer, Motor, and Feeder Protection
  • Class Rating: E
  • Connection: Ferrule
  • AIC rating: 50kA @ 15.5kV
  • Clip Center: 11.5 in


Product Identification
  • UPC: 051712526999
  • GTIN: 00786679109458
