Eaton 15F125HD2A - Medium Voltage Current-Limiting Fuse 125A (15.5kV)

Eaton 15F125HD2A is a medium voltage current-limiting fuse designed for high-voltage circuit protection in industrial power distribution systems. This fuse provides reliable 125A current interruption capability with a 15.5kV voltage rating, engineered to safely clear fault currents in demanding electrical environments. The unit features a robust single-barrel construction with a 3-inch diameter and specialized connection interface, weighing 9 lb for secure installation in compatible switchgear and motor control centers. It complies with relevant industry standards for medium voltage protection devices, ensuring proper coordination within electrical systems. Typical applications include transformer protection, feeder circuit protection, and motor branch circuit protection in industrial facilities, utilities, and large commercial installations.

Key Features & Specifications

• Type: Medium voltage current-limiting fuse with single-barrel construction
• Voltage Rating: 15,500V AC
• Current Rating: 125A
• Dimensions: 3-inch diameter
• Weight: 9 lb
• Connection: Special interface for medium voltage applications
• Barrels: 1
• Item Subcategory: Medium Voltage
• Standards: Complies with industry standards for medium voltage protection
• Applications: Transformer protection, feeder circuit protection, motor branch circuit protection in industrial and utility systems
