Eaton 15BHLE-80E - Medium Voltage Fuse 80A 15.5kV

Eaton
Price
Save $386.15
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Eaton 15BHLE-80E is a medium voltage current-limiting fuse designed for the protection of transformers, motors, and feeders in industrial power distribution systems. It features a 15.5kV voltage rating and an 80A continuous current rating, with a high interrupting capacity of 63kA at 15.5kV. The fuse is constructed as a single-barrel, bolt-on unit with a 3-inch diameter and a 15-inch clip center spacing, housed within a robust package measuring 22.25 x 3.6 x 3 inches and weighing 10 lb. It complies with the IEEE Std. C37.41 standard, ensuring reliable performance for Class E protection applications in demanding electrical environments.

Key Features & Specifications
  • Type: BHLE, Medium Voltage Current-Limiting Power Fuse, Single Barrel
  • Voltage Rating: 15500V AC
  • Current Rating: 80A
  • Dimensions: 22.25 in (L) x 3.6 in (H) x 3 in (W)
  • Standards: IEEE Std. C37.41
  • Applications: Protection for transformers, motors, and feeders
  • AIC rating: 63kA @ 15.5kV
  • Connection: Bolt-On
  • Barrels: 1
  • Class Rating: E
  • Diameter: 3 in
  • Clip Center: 15 in
  • Weight: 10 lb


Product Identification
  • UPC: 782116108183
  • GTIN: 00782116108183
