Eaton 15BHLE-20E - Class E Medium Voltage Fuse 20A 15.5kV

Eaton
Price
Save $1,821.58
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Eaton 15BHLE-20E is a medium voltage current-limiting power fuse designed for the protection of transformers, motors, and feeders in industrial power distribution systems. It features a 20A current rating and a 15.5kV voltage rating, with a high interrupting capacity of 63kA to safely clear fault currents. The fuse is constructed as a single-barrel, bolt-on unit with a 3-inch diameter and a clip center spacing of 15 inches, housed within a robust assembly measuring 22.25" L x 3.6" H x 3" W and weighing 10 lb. It complies with IEEE Std. C37.41 and carries a Class E rating, ensuring reliable performance in demanding medium-voltage applications such as utility substations and large industrial facilities.

Key Features & Specifications
  • Type: Medium Voltage Current-Limiting Power Fuse, Single Barrel, Bolt-On Connection
  • Voltage Rating: 15500V
  • Current Rating: 20A
  • Dimensions: 22.25 in (L) x 3.6 in (H) x 3 in (W)
  • Standards: IEEE Std. C37.41
  • Applications: Transformer, Motor, and Feeder Protection in Industrial Power Systems
  • AIC rating: 63kA @ 15.5kV
  • Class Rating: E
  • Diameter: 3 in
  • Clip Center: 15 in
  • Weight: 10 lb
  • Country of Origin: Dominican Republic


Product Identification
  • UPC: 782116108121
  • GTIN: 00782116108121
