Bussmann 155GXQSJ175E - Medium Voltage Fuse 175A (15.5 kV, 65kA AIC)

The Bussmann 155GXQSJ175E is a Class E medium voltage fuse designed for overcurrent protection in industrial power distribution systems. It features a 175A current rating and 15.5 kV voltage rating with a high interrupting capacity of 65kA at rated voltage. The fuse construction utilizes a single-barrel design with DIN connection interface, measuring 89mm in diameter and 20.078 inches in length with a clip center spacing of 537mm. This fuse meets industry standards for medium voltage applications and is typically deployed in motor control centers, transformer protection, and industrial switchgear where reliable overcurrent protection is critical.

Key Features & Specifications

• Type: Medium Voltage Fuse, Class E, single-barrel construction
• Voltage Rating: 15.5 kV
• Current Rating: 175A
• Dimensions: 3.464 in x 20.078 in x 3.464 in (Height x Length x Width)
• Standards: Industry standard medium voltage fuse requirements
• Applications: Industrial power distribution, motor control centers, transformer protection
• AIC rating: [email protected]
• Connection: DIN
• Barrels: 1
• Clip Center: 537mm
• Diameter: 89mm
• Class Rating: E
• Weight: 11.5 lb

Product Identification

• UPC: 051712691918
• GTIN: 00051712691918
