S&C Electric 131500R4 - Type E Fuse Refill 17kV 200A (SM-5 Family)
S&C Electric 131500R4 - Type E Fuse Refill 17kV 200A (SM-5 Family)

S&C Electric 131500R4 - Type E Fuse Refill 17kV 200A (SM-5 Family)

S&C Electric
Price
Save $0
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
S&C Electric 131500R4 is a high-voltage current-limiting fuse refill designed for protecting electrical distribution systems. Rated for 17,000V AC operation with a 200A interrupting capacity, this Type E fuse features a robust condenser-mounted construction with precision-engineered fusible elements. The SM-5 family fuse meets industry standards for high-voltage protection applications, including utility substations and industrial power distribution. Its compact design and reliable performance make it suitable for safeguarding transformers, capacitors, and feeder circuits in demanding electrical environments.

Key Features & Specifications
  • Type: Current-limiting fuse refill, Type E, SM-5 family
  • Voltage Rating: 17,000V AC
  • Current Rating: 200A interrupting capacity
  • Mounting: Condenser style
  • Construction: Precision fusible elements with arc-quenching media
  • Weight: 1 lb
  • Applications: Transformer protection, capacitor banks, feeder circuits
  • Standards: Meets IEEE/ANSI for high-voltage fuses
  • Section: Fuse Refills
