Eaton 129D696G04 - Medium Voltage Fuse 5080V (Class R Ferrule Connection)

Eaton 129D696G04 is a medium-voltage current-limiting fuse designed for high-voltage circuit protection in industrial power systems. Rated for 5080V applications with Class R construction, it features a ferrule connection and single-barrel design for reliable arc interruption. The fuse measures 3" in diameter with 12" clip center spacing, constructed with durable materials for stable performance under extreme electrical loads. It meets industry standards for medium-voltage protection in demanding environments. Typical applications include motor control centers, transformers, and switchgear installations requiring 5kV protection.

Key Features & Specifications

• Type: Medium-voltage current-limiting fuse with Class R rating
• Voltage Rating: 5080V AC
• Connection: Ferrule termination
• Dimensions: 3" diameter, 12" clip center spacing
• Construction: Single-barrel design with arc-quenching filler
• Weight: 9 lb
• Standards: IEEE/ANSI for medium-voltage fuses
• Applications: Industrial switchgear, transformer protection, motor circuits
