Square D VH363 - Fusible Disconnect Switch 600V AC/DC 100A (3-Pole NEMA 1)

Square D VH363 is a fusible safety disconnect switch designed for circuit protection and isolation in industrial applications. This 3-pole switch operates at 600V AC/DC with a 100A current rating and features a compact 9" x 21¾" NEMA 1 enclosure constructed for durable performance. It complies with UL standards (file E2875) and EU RoHS requirements, ensuring reliable operation in three-phase power systems. The switch accommodates H, K, R, and J class fuses and supports wire sizes from AWG 14 to AWG 1/0 for both aluminum and copper conductors, making it suitable for motor control centers and power distribution panels.

Key Features & Specifications

• Type: Fusible safety disconnect switch, 3-pole single configuration
• Voltage Rating: 600V AC/DC
• Current Rating: 100A
• Dimensions: 9 in x 21 3/4 in
• Standards: UL listed file E2875, EU RoHS
• Applications: Industrial power distribution, motor control centers
• Switch Type: Disconnect
• Configuration: Single
• Poles: 3
• Phase: 3
• Wire: 3
• Wire Size: AWG 12 to AWG 1/0, AWG 14 to AWG 1/0, Aluminum/Copper
• Fuse Class: H, K, R, J
• Nema Rating: NEMA 1
• Weight: 19.84 lb
• Certification: EU RoHS, UL listed file E2875
• Country of Origin: United States

Product Identification

• UPC: 060648589418
• GTIN: 03606485894188
