Square D VH221BDSGL is a fusible safety switch designed for providing a visible disconnect and overcurrent protection in industrial and commercial applications. It is rated for 240V AC, 30A, 1-phase operation and features a robust NEMA 4X enclosure measuring 379.22 mm H x 183.39 mm W x 136.75 mm D (14.93 in x 7.22 in x 5.38 in) with a weight of 13.2 lb for durability in harsh environments. The switch is UL listed (file E2877) and constructed as a 2-pole, 3-wire, single configuration disconnect for reliable circuit isolation. Its design is suitable for use in panelboards, motor control centers, and other equipment requiring a secure, fusible disconnect means.
Key Features & Specifications
Type: Fusible Safety Disconnect Switch, NEMA 4X Enclosure
Voltage Rating: 240V AC
Current Rating: 30A
Dimensions: 379.22 mm H x 183.39 mm W x 136.75 mm D (14.93 in x 7.22 in x 5.38 in)
Standards: UL Listed (File E2877)
Applications: Industrial panelboards, motor control, circuit isolation
Switch Type: Fusible Disconnect
Configuration: Single
Poles: 2
Phase: 1
Wire: 3
Nema Rating: NEMA 4X
Certification: UL Listed
Country of Origin: United States
Weight: 13.2 lb
Family: VH
Product Identification
UPC: 060648589303
GTIN: 03606485893037
