Cutler Hammer P3F362RGNH - Fusible Bus Plug 60A 600V 200kA AIC
Cutler Hammer P3F362RGNH - Fusible Bus Plug 60A 600V 200kA AIC
Cutler Hammer P3F362RGNH - Fusible Bus Plug 60A 600V 200kA AIC
Cutler Hammer P3F362RGNH - Fusible Bus Plug 60A 600V 200kA AIC
Cutler Hammer P3F362RGNH - Fusible Bus Plug 60A 600V 200kA AIC
Cutler Hammer P3F362RGNH - Fusible Bus Plug 60A 600V 200kA AIC
Cutler Hammer P3F362RGNH - Fusible Bus Plug 60A 600V 200kA AIC
Cutler Hammer P3F362RGNH - Fusible Bus Plug 60A 600V 200kA AIC

Cutler Hammer P3F362RGNH - Fusible Bus Plug 60A 600V 200kA AIC

Cutler Hammer
Price
Save $-247.71
/
Condition
  • Low stock - 9 items left
  • Backordered, shipping soon
Call for Price
The Cutler Hammer P3F362RGNH is a fusible bus plug from the Pow-R-Way III family designed to provide branch circuit protection and isolation in industrial power distribution systems. It is rated for 600V AC and a continuous current of 60A in three-phase applications, featuring a 200kA interrupting capacity at rated voltage for high fault protection. The unit is constructed with a robust enclosure measuring 17.92" L x 14.88" H x 8.37" W and weighs 40 lb, utilizing Class R fuse technology for enhanced safety and coordination. It is certified to ANSI, UL 857, IEEE, and CSA standards, ensuring compliance for use in demanding environments such as manufacturing plants, data centers, and other facilities with critical busway power distribution requirements.

Key Features & Specifications
  • Type: Fusible Bus Plug, Pow-R-Way III Family (P3F)
  • Voltage Rating: 600V AC
  • Current Rating: 60A
  • Phase: 3
  • AIC Rating: 200kA @ 600V
  • Fuse Class: R
  • Wire Size: 4 AWG
  • Dimensions: 17.92 in (L) x 14.88 in (H) x 8.37 in (W)
  • Weight: 40 lb
  • Standards & Certification: ANSI, UL 857, IEEE, CSA
  • Country of Origin: Mexico


Product Identification
  • UPC: 786685483054
  • GTIN: 00786685483054
