Bussmann NON-1-1/2 - Low Voltage Fuse 1A 250V (K5 Class 50kA AIC)

The Bussmann NON-1-1/2 is a low-voltage current-limiting fuse designed for protecting electrical circuits and equipment from overcurrent and short-circuit conditions. It features a 1A current rating and a 250V AC voltage rating, providing reliable performance in demanding industrial environments. The fuse is constructed as a single-barrel device with a 0.56-inch diameter and 2-inch length, built to K5 class specifications for current limitation. It meets multiple industry standards including UL listing and CSA certification, ensuring compliance with safety requirements. This fuse is typically applied in industrial control circuits, motor branch circuits, and feeder circuits where high interrupting capacity is essential for system protection.

Key Features & Specifications

• Type: NON Series, Low Voltage Current-Limiting Fuse, Single Barrel
• Voltage Rating: 250V AC
• Current Rating: 1A
• Dimensions: 2 inches length, 0.56 inches diameter
• Standards: UL Listed (File E4274), CSA Certified (Class 1421-01, File 53787), CE, Guide JDDZ, STD 248-9
• Applications: Industrial control circuits, motor protection, feeder circuits
• AIC rating: 50kA@250V
• Class Rating: K5
• Barrels: 1
• Weight: 1.35 lb
• Family: NON Series
• Country of Origin: Mexico

Product Identification

• UPC: 051712300179
• GTIN: 00051712300179
