Bussmann KAC-5 - Low Voltage Fuse 5A (200kA AIC @600V)

Bussmann KAC-5 is a low-voltage fuse designed for circuit protection in industrial electrical systems, featuring a 5A current rating and 600V voltage capacity. Its compact stud-mounted design measures 0.5" (L) x 2.84" (H) x 0.5" (W) with a 0.56" diameter barrel, constructed for high-interrupting capacity applications. UL Recognized and CE Marked, this fuse meets stringent safety standards with a 200kA AIC rating at 600V. Typical applications include motor control centers, switchgear, and power distribution equipment requiring reliable overcurrent protection.

Key Features & Specifications

• Type: KAC series low-voltage fuse with stud connection
• Voltage Rating: 600V AC/DC
• Current Rating: 5A
• Dimensions: 0.5" x 2.84" x 0.5" (LxHxW)
• Standards: UL Recognized, CE Marked
• Applications: Industrial power distribution, motor protection
• AIC rating: 200kA@600V
• Connection: Stud
• Barrels: 1
• Diameter: 0.56"
• Weight: 1 lb
• Certification: UL Recognized, CE Marked

Product Identification

• UPC: 051712470056
• GTIN: 00051712470056
