Bussmann KAC-225 - Current-Limiting Fuse 225A (200kA@600V AIC Rating)

Bussmann KAC-225 is a low-voltage current-limiting fuse designed for industrial circuit protection applications requiring high interrupting capacity. It features a 600V AC voltage rating with a 225A current rating and provides 200kA interrupting capacity at 600V for reliable short-circuit protection. The fuse construction utilizes a single-barrel design with stud connections and measures 6.182 inches in length with a 2-inch diameter, weighing approximately 1 pound. Certified to UL Recognized and CE Marked standards, this fuse meets rigorous safety requirements for industrial electrical systems. Typical applications include motor circuit protection, industrial control panels, and power distribution equipment where high fault current interruption is critical.

Key Features & Specifications

• Type: KAC Series current-limiting fuse, single-barrel construction with stud connections
• Voltage Rating: 600V AC
• Current Rating: 225A
• Dimensions: 6.182" L × 6.1" H × 2.1" W (157mm × 155mm × 53mm)
• Standards: UL Recognized, CE Marked
• Applications: Industrial circuit protection, motor protection, power distribution systems
• AIC rating: 200kA@600V
• Connection: Stud
• Barrels: 1
• Diameter: 2 inches (51mm)
• Weight: 1 lb (0.45 kg)
• Certification: UL Recognized, CE Marked
• Family: KAC Series
• Item Subcategory: Low Voltage Fuse

Product Identification

• UPC: 051712472258
• GTIN: 00051712472258
