Siemens JXD22B225 - Molded Case Circuit Breaker 225A 240V 1P
Siemens JXD22B225 - Molded Case Circuit Breaker 225A 240V 1P

Siemens JXD22B225 - Molded Case Circuit Breaker 225A 240V 1P

Siemens
Price
Save $3,907.03
/
Condition
  • Low stock - 6 items left
  • Backordered, shipping soon
Call for Price
Siemens JXD22B225 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in industrial electrical systems. It features a 225A current rating and a 240V AC voltage rating, housed within a compact, robust frame measuring 8.661" x 12.992" x 6.695" (220 x 330 x 170 mm) and weighing 15.201 lb. This thermal-magnetic breaker complies with UL and IEC standards and is RoHS compliant, ensuring safe operation across a temperature range of -25°C to 70°C. Its typical applications include integration into SB switchboards and Sentron panelboards for safeguarding single-phase circuits.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal Magnetic Protection, Standard Breaker Type, Bolt-On Connection
  • Voltage Rating: 240V AC
  • Current Rating: 225A
  • Dimensions: 8.661" L x 12.992" W x 6.695" H (220 x 330 x 170 mm)
  • Standards: RoHS Compliant
  • Applications: SB Switchboards (Without Lugs), Sentron Panelboards
  • Phase: 1
  • AIC Rating: 65kA @ 240V
  • Poles: 2
  • Protection: Thermal Magnetic
  • Functions: LI (Long-Time and Instantaneous Trip)
  • Frame Size: 400A/JD
  • Breaker Type: Standard
  • Temp Rating: -25°C to 70°C (-13°F to 158°F)
  • Connection: Bolt-On
  • Terminal Connection: Lug (Lugs Not Included)
  • Panel Type: SB Switchboards Without Lugs, Sentron Panelboards
  • Certification: UL, IEC
  • Phase Connection: Not Applicable
  • MCM Size: 500 MCM
  • Weight: 15.201 lb


Product Identification
  • UPC: 783643212879
  • GTIN: 00783643212879
