Bussmann JJS-150 - Class T Fuse 150A (200kA@600V Interrupting Rating)

The Bussmann JJS-150 is a Class T low-voltage fuse designed for high-interrupting capacity circuit protection in industrial applications. It features a 150A current rating and 600V voltage rating with an impressive 200kA interrupting capacity at rated voltage. The fuse construction includes a single-barrel design measuring 3-1/4 inches in length with a 0.88-inch diameter and weighs 1 lb. It complies with CE/UL-248-15 Guide JDDZ and CSA Class 1422-02 standards, ensuring reliable performance in demanding environments such as industrial control panels, motor circuits, and power distribution systems where high fault current protection is critical.

Key Features & Specifications

• Type: Class T low-voltage fuse, single-barrel construction
• Voltage Rating: 600V AC
• Current Rating: 150A
• Dimensions: 3-1/4 inches length, 0.88 inches diameter
• Standards: CE/UL-248-15 Guide JDDZ, CSA Class 1422-02
• Applications: Industrial control panels, motor protection, power distribution
• AIC rating: 200kA@600V
• Class Rating: T
• Barrels: 1
• Weight: 1 lb
• Family: T-Tron
• Country of Origin: Mexico

Product Identification

• UPC: 051712628167
• GTIN: 00051712628167
