Square D HOM230EPD is a molded case circuit breaker designed for providing reliable overcurrent protection in residential and light commercial electrical panels. It features a 30A current rating and a 240V AC voltage rating, housed within a compact, plug-in design for straightforward installation. The unit is constructed with screw clamp terminals and supports wire sizes from 14 AWG to 8 AWG for both copper and aluminum conductors, operating effectively within a temperature range of -25 to 70 °C. It complies with UL standards and utilizes a thermal-magnetic trip mechanism offering both long-time and instantaneous protection functions with an interrupting capacity of 10kA at 240V. This breaker is typically applied in single-phase systems for safeguarding branch circuits powering appliances, HVAC equipment, and other high-demand loads.

Key Features & Specifications
  • Type: Molded Case, Thermal-Magnetic Protection, Plug-In Connection
  • Voltage Rating: 240V AC
  • Current Rating: 30A
  • Poles: 2
  • AIC Rating: 10kA @ 240V
  • Phase: 1
  • Connection: Plug-In
  • Terminal Connection: Screw Clamp Terminals
  • Wire Size: 14 AWG to 8 AWG (Copper/Aluminum)
  • Temp Rating: -25°C to 70°C (-13°F to 158°F)
  • Protection: Thermal Magnetic
  • Functions: Long Time and Instantaneous
  • Standards/Certification: UL Listed
  • Frame: HOM
  • Family: HOMELINE
  • Dimensions: 267.46 mm D x 406.40 mm W x 1333.50 mm H (10.53 in x 16 in x 52.5 in)
  • Weight: 1.16 lb
  • Country of Origin: Mexico


Product Identification
  • UPC: 785901682769
  • GTIN: 00785901682769
