Square D
Price
Save $266.18
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Square D HOM2150 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in residential and light commercial electrical systems. It features a 150A current rating and a 120/240V AC voltage rating, housed within a compact plug-in frame measuring 79.5 mm H x 50.8 mm W x 75.69 mm D and weighing 1.76 lb. The breaker is constructed with a thermal-magnetic trip mechanism for both long-time delay and instantaneous protection, is CSA Certified, UL Listed, and HACR approved, and is engineered for compatibility with Homeline load centers. Its typical applications include serving as a main circuit breaker for panel protection, with lug terminals accommodating wire sizes from 8 AWG to 2 AWG and an interrupting capacity of 10kA at 240V AC.

Key Features & Specifications
  • Type: Molded Case, Standard, Thermal-Magnetic Protection (LI Trip)
  • Voltage Rating: 120/240V AC
  • Current Rating: 150A
  • Dimensions: 79.5 mm H x 50.8 mm W x 75.69 mm D (3.13 in x 2 in x 2.98 in)
  • Standards: CSA Certified, HACR, UL Listed
  • Applications: Main circuit protection for Homeline load centers
  • Switch Type: Circuit Breaker
  • Configuration: Plug-In
  • Temp Rating: -25 to 70 °C (-13 to 158 °F)
  • Phase: 1
  • AIC Rating: 10kA @ 240V AC
  • Connection: Plug-In, Lug Terminal
  • Poles: 2
  • Protection: Thermal Magnetic
  • Functions: Long-Time and Instantaneous Trip (LI)
  • Frame Size: 100A/HOM
  • Trip Type: Thermal Magnetic
  • Panel Type: Homeline Load Center
  • Breaker Type: Standard
  • MCM Size: Min. 8 AWG, Max. 2 AWG
  • Wire Size: 1x AWG 4 to 300 KCMil, Aluminum/Copper
  • Certification: CSA Certified, HACR, UL Listed
  • Terminal Connection: Lug
  • Frequency Rating: 50/60 Hz
  • Phase Connection: Single Phase
  • Compatible Frames: Homeline
  • Installation Type: Plug-In Mount
  • Breaker Frame: HOM
  • Weight: 1.76 lb


Product Identification
  • UPC: 785901065838
  • GTIN: 00785901065838
