Siemens HNF462J - Non-Fusible Disconnect Switch 60A 600V 5-Pole

Price
Regular price $0.00
Regular price Sale price $0.00
Save $0
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Siemens HNF462J is a non-fusible disconnect switch designed for providing a visible break and isolation in three-phase industrial power circuits. It is rated for 600V AC and a continuous current of 60A, featuring a bolt-on connection for five poles within a robust NEMA 12 enclosure measuring 29.921 x 15.748 x 10.63 inches and weighing 45.085 lb. This solid-state protection device is UL listed and offers an interrupting capacity of 200kA at 600V, ensuring compliance with rigorous safety and performance standards. It is engineered for integration into compatible PGP frames, making it suitable for motor control centers and industrial distribution panels where reliable circuit isolation is required.

Key Features & Specifications
  • Type: Non-Fusible Disconnect Switch, HNF type, VBII Series, Solid State protection with LI (Long-Time and Instantaneous) functions
  • Voltage Rating: 600V AC
  • Current Rating: 60A
  • Configuration: Single
  • Poles: 5
  • Connection: Bolt-On
  • Phase: 3
  • AIC Rating: 200kA @ 600V
  • Class Rating: RK5
  • Wire: 4
  • NEMA Rating: NEMA 12
  • Dimensions: 29.921" x 15.748" x 10.63"
  • Weight: 45.085 lb
  • Certification: UL listed
  • Compatible Frames: PGP
  • Switch Style: Non-Fusible
  • Country of Origin: Mexico


Product Identification
  • UPC: 783643488458
