Siemens HNF364R - Non-Fusible Disconnect Switch 200A 600V

Price
Regular price $0.00
Regular price Sale price $0.00
Save $0
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Siemens HNF364R is a non-fusible disconnect switch designed for providing a visible means of isolation and safe maintenance of three-phase industrial power circuits. It is rated for 600V AC systems with a continuous current rating of 200A and a high interrupting capacity of 200kA at 600V. The switch features a robust, single-configuration design with three poles, is housed in a NEMA 3R enclosure for outdoor durability, and is UL listed for safety compliance, making it suitable for use in motor control centers, industrial panels, and power distribution equipment.

Key Features & Specifications
  • Type: Non-Fusible Disconnect Switch, HNF type, VBII Series
  • Voltage Rating: 600V AC
  • Current Rating: 200A
  • Dimensions: 33.858" x 18.898" x 9.843"
  • Weight: 35.294 lb
  • Standards: UL Listed, NEMA 3R Enclosure Rating
  • Applications: Industrial power isolation, motor control centers, panelboards
  • Switch Style: Non-Fusible
  • Configuration: Single
  • Poles: 3
  • Phase: 3
  • AIC Rating: 200kA @ 600V
  • Compatible Frames: PGP
  • Country of Origin: Mexico


Product Identification
  • UPC: 783643151765
  • GTIN: 0783643151765
