Siemens HNF363S - Non-Fusible Disconnect Switch 100A 600V

Siemens
Price
Save $0
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Siemens HNF363S is a non-fusible disconnect switch designed for providing a visible safety break and isolation in three-phase industrial power circuits. It is rated for 600V AC systems with a continuous current capacity of 100A and features a robust 3-pole, single-configuration design housed in a NEMA 4X enclosure for protection against corrosion and weather. The switch is constructed with durable materials for reliable operation across a wide temperature range from -25°C to 70°C (-13°F to 158°F) and is part of the VBII series, compatible with PGP frames. It complies with UL standards and offers a high interrupting capacity of 200kA at 600V, making it suitable for use in industrial control panels, motor control centers, and machinery where a visible disconnect is required for maintenance and safety.

Key Features & Specifications
  • Type: Non-Fusible Disconnect Switch, HNF Type, VBII Series
  • Voltage Rating: 600V AC
  • Current Rating: 100A
  • Configuration: Single
  • Poles: 3
  • Phase: 3
  • AIC Rating: 200kA @ 600V
  • NEMA Rating: NEMA 4X
  • Temp Rating: -25°C to 70°C (-13°F to 158°F)
  • Dimensions: 17.323" x 7.874" x 6.299" (440mm x 200mm x 160mm)
  • Weight: 24.0 lb (10.9 kg)
  • Standards: UL Listed
  • Compatible Frames: PGP
  • Switch Style: Non-Fusible
  • Applications: Industrial control panels, motor control centers, machinery isolation
  • Country of Origin: Mexico


Product Identification
  • UPC: 783643152120
  • GTIN: 0783643152120
