Siemens HNF362JCH - Non-Fusible Disconnect Switch, 60A 600V 3-Pole

Price
Regular price $0.00
Regular price Sale price $0.00
Save $0
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Siemens HNF362JCH is a non-fusible disconnect switch designed for providing a visible break and safe isolation in three-phase industrial power circuits. It is rated for 600V AC systems with a continuous current rating of 60A and a high interrupting capacity of 200kA at 600V. The switch is constructed within a robust NEMA 12 enclosure measuring 13.78 x 7.874 x 27.953 inches and weighing 28.065 lb, ensuring protection against dust and dripping liquids. It is UL listed and part of the Siemens VBII series, designed for compatibility with PGP frames. This switch is typically applied in motor control centers and industrial distribution panels where reliable load breaking and safety isolation are required.

Key Features & Specifications
  • Type: HNF Series, Non-Fusible Disconnect Switch, Manual Operation
  • Voltage Rating: 600V AC
  • Current Rating: 60A
  • Configuration: Single Unit
  • Poles: 3
  • Phase: 3-Phase
  • AIC Rating: 200kA @ 600V
  • NEMA Rating: NEMA 12 Enclosure
  • Dimensions: 13.78" x 7.874" x 27.953" (350mm x 200mm x 710mm)
  • Weight: 28.065 lb (12.73 kg)
  • Standards: UL Listed
  • Compatible Frames: PGP
  • Family: VBII Series
  • Country of Origin: Mexico


Product Identification
  • UPC: 783643436008
  • GTIN: 0783643436008
