Square D HJA36025 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in three-phase industrial power distribution systems. It features a 25A current rating and a 600V AC voltage rating, housed within a compact H-frame construction measuring 163 mm H x 104 mm W x 86 mm D and weighing 5.42 lb. The breaker utilizes a thermal-magnetic trip unit for both long-time and instantaneous protection, is rated for 65kA interrupting capacity at 480V, and operates within a temperature range of -25 to 70 °C. It complies with UL, CSA, NEMA, and IEC 60947-2 standards, ensuring suitability for a wide range of commercial and industrial panelboard applications. Its I-Line style plug-in connection with lug terminals facilitates efficient installation, accommodating wire sizes from 14 AWG to 3/0 AWG for both copper and aluminum conductors.

Key Features & Specifications
  • Type: HJA Molded Case Circuit Breaker, Thermal Magnetic Protection
  • Voltage Rating: 600V AC
  • Current Rating: 25A
  • Dimensions: 163 mm H x 104 mm W x 86 mm D (6.4 in x 4.09 in x 3.4 in)
  • Weight: 5.42 lb
  • Standards: UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
  • Applications: Industrial Power Distribution, Panelboards
  • Switch Type: Circuit Breaker
  • Configuration: 3-Pole
  • Temp Rating: -25 to 70 °C (-13 to 158 °F)
  • Phase: 3
  • AIC Rating: 65kA @ 480V
  • Connection: I-Line Style Plug-In
  • Poles: 3
  • Protection: Thermal Magnetic
  • Functions: Long Time and Instantaneous Trip
  • Frame Size: H
  • Terminal Connection: I-Line, Lug
  • Wire Size: 14 AWG to 3/0 AWG (Cu/Al)
  • Certification: UL, CSA, NOM
  • Phase Connection: ABC
  • MCM Size: Min. 14 AWG, Max. 3/0 AWG (Cu/Al)
  • Manufacturer: Schneider Electric
  • Family: Powerpact
  • Country of Origin: Mexico


Product Identification
  • UPC: 785901507291
  • GTIN: 00785901507291
