Square D HGL26050 - 50A 2-Pole Molded Case Circuit Breaker

Price
Regular price $510.80
Regular price $1,269.00 Sale price $510.80
Save $758.20
/
Condition
  • Low stock - 4 items left
  • Backordered, shipping soon
The Square D HGL26050 is a molded case circuit breaker from the PowerPact family designed to provide reliable thermal-magnetic protection for electrical circuits. It features a 50A current rating and a 600V voltage rating, housed within a compact 150A/HG frame measuring 163 mm H x 104 mm W x 86 mm D and weighing 3.001 lb. This bolt-on, 2-pole breaker is constructed for compliance with UL, CSA, NEMA, NOM, and IEC 60947-2 standards and operates effectively across a temperature range of -25 to 70 °C. Its 35kA interrupting capacity at 480V and line/load lug terminals compatible with AWG 14 to 3/0 wire make it suitable for a variety of industrial power distribution applications.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal Magnetic Protection, Standard Type
  • Voltage Rating: 600V AC
  • Current Rating: 50A
  • Frame Size: 150A/HG
  • Poles: 2
  • Connection: Bolt-On
  • AIC Rating: 35kA @ 480V
  • Phase: 1
  • Functions: Long Time and Instantaneous
  • Terminal Connection: Line/Load Lug
  • Wire Size: AWG 14 to AWG 3/0 (Aluminium/Copper)
  • Temp Rating: -25°C to 70°C (-13°F to 158°F)
  • Dimensions: 163 mm H x 104 mm W x 86 mm D (6.4 in x 4.09 in x 3.4 in)
  • Weight: 3.001 lb
  • Standards: UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
  • Certification: UL, CSA, NOM
  • Country of Origin: Mexico


Product Identification
  • UPC: 785901883777
  • GTIN: 00785901883777
