Square D HGL26020 - Molded Case Circuit Breaker 20A 600V 2-Pole

Price
Regular price $449.76
Regular price $1,269.00 Sale price $449.76
Save $819.24
/
Condition
  • Low stock - 7 items left
  • Backordered, shipping soon
Square D HGL26020 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in industrial electrical systems. It features a 20A current rating and a 600V AC voltage rating, housed within a compact 150A/HG frame with dimensions of 163 mm H x 104 mm W x 86 mm D and a weight of 3.001 lb. This thermal magnetic, bolt-on, two-pole breaker is constructed for operation in temperatures from -25 to 70 °C and complies with UL, CSA, NEMA, and IEC 60947-2 standards. Its 35kA interrupting capacity at 480V and compatibility with wire sizes from 14 AWG to 3/0 AWG make it suitable for protecting feeders and branch circuits in commercial and industrial panelboards.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal Magnetic Protection, Standard, Bolt-On Connection
  • Voltage Rating: 600V AC
  • Current Rating: 20A
  • Frame Size: 150A/HG
  • Poles: 2
  • AIC Rating: 35kA @ 480V AC
  • Phase: 1
  • Connection: Bolt-On, Line/Load Lug Terminal
  • Wire Size: 14 AWG to 3/0 AWG (Aluminium/Copper)
  • Dimensions: 6.4 in H (163 mm) x 4.09 in W (104 mm) x 3.4 in D (86 mm)
  • Weight: 3.001 lb
  • Operating Temperature: -25°C to 70°C (-13°F to 158°F)
  • Standards & Certification: UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
  • Functions: Long Time and Instantaneous Trip
  • Family: Powerpact
  • Country of Origin: Mexico


Product Identification
  • UPC: 785901433767
  • GTIN: 00785901433767
