Siemens HGB3B070B - Molded Case Circuit Breaker 70A 600V 3P
Siemens HGB3B070B - Molded Case Circuit Breaker 70A 600V 3P

Siemens HGB3B070B - Molded Case Circuit Breaker 70A 600V 3P

Siemens
Price
Save $2,662.68
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Siemens HGB3B070B is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in three-phase electrical systems. It features a 70A current rating and a 600V voltage rating, housed within a compact, bolt-on configuration measuring 2.961" x 2.87" x 4.1008" and weighing 2.756 lb. The breaker complies with UL, CSA, IEC, and NOM standards and utilizes a thermal-magnetic trip unit with long-time and instantaneous (LI) functions for coordinated protection. Its 100kA interrupting capacity at 240V and operating temperature range of -25°C to 70°C make it suitable for industrial panelboards, switchgear, and commercial power distribution applications.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection, Bolt-On Connection
  • Voltage Rating: 600V AC
  • Current Rating: 70A
  • Dimensions: 2.961" H x 2.87" W x 4.1008" D (75.2mm x 72.9mm x 104.2mm)
  • Standards: UL, CSA, IEC, NOM Certified
  • Applications: Industrial Panelboards, Switchgear, Commercial Power Distribution
  • Phase: 3
  • AIC Rating: 100kA @ 240V
  • Poles: 3
  • Protection: Thermal Magnetic
  • Functions: LI (Long Time and Instantaneous)
  • Connection: Bolt-On
  • Wire Size: 8 to 1/0 AWG CU/AL
  • Temp Rating: -25°C to +70°C (-13°F to 158°F)
  • Weight: 2.756 lb
  • Family: VL Series
  • Country of Origin: Mexico


Product Identification
  • UPC: 887621219857
  • GTIN: 00887621219857
