Siemens HGB2B100B - Molded Case Circuit Breaker 100A 600V 2-Pole
Siemens HGB2B100B - Molded Case Circuit Breaker 100A 600V 2-Pole

Siemens HGB2B100B - Molded Case Circuit Breaker 100A 600V 2-Pole

Siemens
Price
Save $2,155.18
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Siemens HGB2B100B is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in industrial electrical systems. It features a 100A current rating and a 600V AC voltage rating, housed within a compact, bolt-on configuration measuring 1.969" x 2.87" x 4.100" and weighing 1.852 lb. The breaker utilizes a thermal-magnetic trip unit for combined long-time and instantaneous (LI) protection functions and is certified to UL, CSA, IEC, and NOM standards for safety and interoperability. Its 100kA interrupting rating at 240V AC and operational temperature range of -25°C to 70°C make it suitable for a variety of commercial and industrial panelboard applications.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal-Magnetic Protection, Bolt-On Connection
  • Voltage Rating: 600V AC
  • Current Rating: 100A
  • Dimensions: 1.969" H x 2.87" W x 4.100" D (50mm x 73mm x 104mm)
  • Standards: UL, CSA, IEC, NOM
  • Applications: Industrial Panelboards, Commercial Electrical Distribution
  • Poles: 2
  • Phase: 1
  • AIC Rating: 100kA @ 240V AC
  • Connection: Bolt-On
  • Protection: Thermal Magnetic
  • Functions: Long-Time and Instantaneous (LI)
  • Wire Size: 8 - 1/0 AWG (Copper/Aluminum)
  • Temp Rating: -25°C to +70°C (-13°F to 158°F)
  • Weight: 1.852 lb (0.84 kg)
  • Family: VL Series
  • Country of Origin: Mexico


Product Identification
  • UPC: 887621219734
  • GTIN: 00887621219734
