Siemens HGB2B090B - Molded Case Circuit Breaker 90A 600V 2-Pole
Siemens HGB2B090B - Molded Case Circuit Breaker 90A 600V 2-Pole

Siemens HGB2B090B - Molded Case Circuit Breaker 90A 600V 2-Pole

Siemens
Price
Save $2,155.18
/
Condition
  • Low stock - 9 items left
  • Backordered, shipping soon
Call for Price
Siemens HGB2B090B is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in industrial electrical systems. It features a 90A current rating and a 600V voltage rating, housed in a compact, bolt-on configuration measuring 1.969" x 2.87" x 4.999" and weighing 1.852 lb. This thermal magnetic breaker complies with UL, CSA, IEC, and NOM standards and is engineered for a wide operating temperature range from -25°C to 70°C, making it suitable for panelboards, switchboards, and industrial control panels where robust protection is required.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal Magnetic Protection, HGB Type
  • Voltage Rating: 600V AC
  • Current Rating: 90A
  • Dimensions: 1.969" x 2.87" x 4.999" (50mm x 73mm x 127mm)
  • Standards: UL, CSA, IEC, NOM
  • Applications: Panelboards, Switchboards, Industrial Control Panels
  • Switch Type: Circuit Breaker
  • Configuration: Bolt-On
  • Temp Rating: -25°C to 70°C (-13°F to 158°F)
  • Phase: 1
  • AIC Rating: 100kA @ 240V
  • Connection: Bolt-On
  • Poles: 2
  • Protection: Thermal Magnetic
  • Functions: LI - Long-Time and Instantaneous Trip
  • Wire Size: 8 - 1/0 AWS (CU/AL)
  • Certification: UL, CSA, IEC, NOM
  • Family: VL Series
  • Country of Origin: Mexico
  • Weight: 1.852 lb


Product Identification
  • UPC: 887621219727
  • GTIN: 00887621219727
