Siemens HGB2B035B - Molded Case Circuit Breaker, 35A 600V 2-Pole
Siemens HGB2B035B - Molded Case Circuit Breaker, 35A 600V 2-Pole

Siemens HGB2B035B - Molded Case Circuit Breaker, 35A 600V 2-Pole

Siemens
Price
Save $1,862.63
/
Condition
  • Low stock - 4 items left
  • Backordered, shipping soon
Call for Price
Siemens HGB2B035B is a molded case circuit breaker designed for providing reliable thermal-magnetic protection against overloads and short circuits in electrical circuits. It is rated for 35A at 600V AC and features a compact, bolt-on design with dimensions of 1.969" x 2.87" x 4.992" (50mm x 73mm x 127mm) and a weight of 1.852 lb. The breaker is certified to UL, CSA, IEC, and NOM standards and operates effectively within a temperature range of -25°C to 70°C (-13°F to 158°F). Its typical applications include industrial control panels, distribution boards, and machinery where robust circuit protection for 8 to 1/0 AWG copper or aluminum conductors is required.

Key Features & Specifications
  • Type: Molded Case Circuit Breaker, Thermal Magnetic Protection, HGB Type
  • Voltage Rating: 600V AC
  • Current Rating: 35A
  • Dimensions: 1.969" x 2.87" x 4.992" (50mm x 73mm x 127mm)
  • Standards: UL, CSA, IEC, NOM
  • Applications: Industrial control panels, distribution boards, machinery protection
  • Switch Type: Circuit Breaker
  • Configuration: Bolt-On
  • Temp Rating: -25°C to 70°C (-13°F to 158°F)
  • Phase: 1
  • AIC rating: 100kA @ 240V
  • Connection: Bolt-On
  • Poles: 2
  • Protection: Thermal Magnetic
  • Functions: LI (Long Time and Instantaneous)
  • Wire Size: 8 to 1/0 AWG CU/AL
  • Certification: UL, CSA, IEC, NOM
  • Family: VL Series
  • Country of Origin: Mexico
  • Weight: 1.852 lb


Product Identification
  • UPC: 887621219659
  • GTIN: 00887621219659
