Square D HGA260804 - Molded Case Circuit Breaker 80A 600V 2-Pole
Square D HGA260804 - Molded Case Circuit Breaker 80A 600V 2-Pole

Square D HGA260804 - Molded Case Circuit Breaker 80A 600V 2-Pole

Square D
Price
Save $2,551.91
/
Condition
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Square D HGA260804 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in industrial power distribution systems. It features a 600V AC voltage rating and an 80A current rating, housed within a compact 150A/HG frame measuring 163 mm x 104 mm x 86 mm (H x W x D) and weighing 3.001 lb. This thermal-magnetic breaker is constructed for plug-in connection to I-Line panelboards and operates reliably across a temperature range of -25 to 70 °C. It complies with UL, CSA, NEMA, and IEC 60947-2 standards, making it suitable for protecting branch circuits in commercial and industrial facilities.

Key Features & Specifications
  • Type: Standard thermal-magnetic molded case circuit breaker
  • Voltage Rating: 600V AC
  • Current Rating: 80A
  • Frame Size: 150A/HG
  • Poles: 2
  • AIC Rating: 35kA at 480V AC
  • Phase: 1
  • Connection: Plug-in panelboard with lug terminals
  • Protection: Thermal-magnetic with long-time and instantaneous trip functions
  • Wire Size Range: 14 AWG to 3/0 AWG for aluminum/copper
  • Dimensions: 6.4 in (163 mm) H x 4.09 in (104 mm) W x 3.4 in (86 mm) D
  • Weight: 3.001 lb
  • Operating Temperature: -13 to 158 °F (-25 to 70 °C)
  • Standards: UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
  • Panel Type: I-Line Panelboards
  • Phase Connection: BC


Product Identification
  • UPC: 785901491088
  • GTIN: 00785901491088
