Square D HGA260201 - Molded Case Circuit Breaker 20A 600V
Square D HGA260201 - Molded Case Circuit Breaker 20A 600V

Square D HGA260201 - Molded Case Circuit Breaker 20A 600V

Square D
Price
Save $560.19
/
Condition
  • Low stock - 1 item left
  • Backordered, shipping soon
Call for Price
Square D HGA260201 is a molded case circuit breaker designed for providing reliable overcurrent and short-circuit protection in industrial and commercial electrical systems. It features a 20A current rating and a 600V voltage rating, housed within a compact 150A/HG frame measuring 163 mm x 104 mm x 86 mm (H x W x D) and weighing 4.068 lb. This thermal-magnetic breaker is engineered for compliance with UL, CSA, NEMA, NOM, and IEC 60947-2 standards, ensuring robust performance. Its plug-in design makes it suitable for installation in I-Line panelboards, where it provides long-time and instantaneous trip functions for single-phase AB connections.

Key Features & Specifications
  • Type: Standard thermal-magnetic molded case circuit breaker
  • Voltage Rating: 600V
  • Current Rating: 20A
  • Frame Size: 150A/HG
  • AIC Rating: 35kA at 480V
  • Poles: 2
  • Phase: 1
  • Connection: Plug-in panelboard with lug terminals
  • Protection: Thermal-magnetic with long-time and instantaneous trip functions
  • Wire Size: 14 AWG to 3/0 AWG (aluminium/copper)
  • Dimensions: 163 mm x 104 mm x 86 mm (H x W x D)
  • Weight: 4.068 lb
  • Temp Rating: -25 to 70 °C (-13 to 158 °F)
  • Standards: UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
  • Panel Type: I-Line Panelboards
  • Phase Connection: AB


Product Identification
  • UPC: 785901539698
  • GTIN: 00785901539698
