Siemens HF366N - Fusible Disconnect Switch, 600A 600V 3-Pole
Siemens HF366N - Fusible Disconnect Switch, 600A 600V 3-Pole
Siemens HF366N - Fusible Disconnect Switch, 600A 600V 3-Pole
Siemens HF366N - Fusible Disconnect Switch, 600A 600V 3-Pole
Siemens HF366N - Fusible Disconnect Switch, 600A 600V 3-Pole
Siemens HF366N - Fusible Disconnect Switch, 600A 600V 3-Pole

Siemens HF366N - Fusible Disconnect Switch, 600A 600V 3-Pole

Siemens
Price
Save $7,066.57
/
Title
  • In stock, ready to ship
  • Backordered, shipping soon
Call for Price
Siemens HF366N is a fusible disconnect switch designed for providing a visible break and overcurrent protection in three-phase industrial power distribution systems. It is rated for 600A at 600V AC with an interrupting capacity of 200kA, housed in a robust NEMA 1 enclosure measuring 29.921 x 60.63 x 12.992 inches (760 x 1540 x 330 mm) and weighing 171.365 lb. The switch is UL listed and operates reliably within a temperature range of -25°C to 70°C (-13°F to 158°F). Its design is compatible with PGP frames and utilizes Class R fuses, making it suitable for service entrance, motor control centers, and main feeder disconnects.

Key Features & Specifications
  • Type: Fusible Disconnect Switch, VBII Series, HF Type
  • Voltage Rating: 600V AC
  • Current Rating: 600A
  • Configuration: Single, 3-Pole
  • AIC Rating: 200kA at 600V
  • Fuse Class: R
  • Dimensions: 29.921" H x 60.63" W x 12.992" D (760 x 1540 x 330 mm)
  • Weight: 171.365 lb
  • Standards: UL Listed
  • NEMA Rating: NEMA 1
  • Phase: 3
  • Temp Rating: -25°C to 70°C (-13°F to 158°F)
  • Compatible Frames: PGP
  • Switch Style: Fusible
  • Country of Origin: Mexico


Product Identification
  • UPC: 783643151130
  • GTIN: 00783643152007
